woltman irrigaton water flowmeter

  • Size Range: DN40~D300
  • Pulse output: Reed switch
  • Protection: IP67
  • Accuracy: R50, R80
  • Temperature: T50, T90
Share With:
  • Overview
  • Technical Data



Application

♦  Recording the total amount of cold water flowing through the water pipe.


 Features

♦  The full set YT-Flow woltman series of water meters is imported from German technology with removable structure. The water meter does not have to be removed from the pipeline, so the movement can be pulled out repair or replacement.

 ♦  The counter is sealed with copper skin with the advantages of the clear reading kept for a long time, good universality of the measuring mechanism, reduction of spare parts, magnetic connection, small transmission resistance, sensitive and reliable operation, low pressure loss and long service life.

  ♦  All the materials in contact with water, consciously selected by the known resistance to corrosion; Iron body with inside and outside epoxy coating for protecting the corrosion; The ROTATING indicator register for the most comfortable reading position; The copper can super dry register with IP68 protection; The interchangeable, removable measuring mechanism can be easy removed from the body for checking, maintaining and replacing, no needs to dismantle the body form the pipe; Suitable for any position installation; Low pressure loss; No effected by external magnetic fields; Pulse output always ready, and Pulse output AS OPTION; The Pulse Output Device consists of a plastic housing with a Reed Switch, and 1,5 m cable with 2 cores in Red and Black; Electric Data: Vmax=24AC/DC; Imax=0,01A;

Remarks

♦  The technical parameters of the water meter are in accordance with the national standard GB/T 778.1~3-2007 (ISO4064-1~3:2005, IDT).

♦  The YT-Flow woltman DN40~600 hot water meter is available. The highest temperature can reach 130℃ and the counter can rotate at 360°.

♦  It is TURBINE Woltaman water meter with magnetic transmission, super dry type register for Industrial and Irrigation application has the sizes from Dn40 to Dn600 designed by YT-Flow and meets to the requirements of Directive 2004/22/EC on measuring instruments and of European Standard EN14154.

Capacity of the Pulse Emitter:

Size

m3/pulse

Dn40 to Dn125

0.1

1

Dn150 to Dn200

1

10

Dn250 to Dn600

10

100
